The Westinghouse FA3020PF-R is a popular molded case circuit breaker (MCCB) designed to protect electrical systems from overloads and short circuits. Used widely in industrial, commercial, and even older residential applications, this circuit breaker is known for its durability, precision, and long service life.
Understanding its features and specifications is important for anyone dealing with electrical system design, maintenance, or upgrades—especially where legacy systems are involved.
Product Overview
The FA3020PF-R is part of Westinghouse’s respected FA series of molded case circuit breakers. Westinghouse, a trusted name in the electrical industry for decades, originally manufactured this model. Though no longer in active production by the brand, the Westinghouse FA3020PF-R remains in circulation through surplus distributors and reconditioned equipment suppliers.
This breaker is typically used in panel boards, switchboards, and motor control centers, where it serves as a protective device. Its popularity stems from its ability to perform reliably in both high-demand industrial settings and complex electrical distribution networks.
Technical Specifications
The Westinghouse FA3020PF-R circuit breaker offers the following key specifications:
| Attribute | Value |
|---|---|
| Manufacturer | Westinghouse |
| Model Number | FA3020PF-R |
| Frame Type | FA Frame |
| Poles | 3-Pole |
| Amperage Rating | 20 Amps |
| Voltage Rating | 600 VAC |
| Interrupting Capacity | 14 kA at 480 VAC |
| Trip Type | Thermal-Magnetic |
| Connection Type | Bolt-On |
| Load Side Terminal | Lugs |
These features make the FA3020PF-R an excellent choice for environments that demand a reliable and safe way to interrupt current flow when faults occur.
Design and Construction
One of the defining features of the Westinghouse FA3020PF-R is its molded case design. Molded case circuit breakers are enclosed in a hard, insulated material that protects the internal components and provides durability in challenging environments.
The breaker operates using thermal-magnetic trip technology. This means it has two distinct trip elements: one thermal, which provides overload protection, and one magnetic, which responds to short circuits almost instantly. This dual mechanism ensures precise and effective protection.
Another useful design feature is the bolt-on connection style. This allows for quick and secure installation, especially in tight panel spaces. The inclusion of load side lugs also simplifies the process of attaching conductors during setup or maintenance.
Functionality and Performance
The Westinghouse FA3020PF-R is engineered for both long-time and instantaneous trip functionality. The long-time trip element allows the breaker to tolerate temporary overloads—such as motor startups—without tripping.
However, sustained overloads will trigger a shutdown, thereby protecting the connected equipment. On the other hand, the instantaneous trip mechanism activates immediately when it detects a short circuit or severe fault current.
Its interrupting capacity of 14,000 amperes at 480 volts is suitable for many industrial and commercial applications. This high fault tolerance ensures system stability, especially in systems where a sudden spike in current could cause widespread damage.
Installation and Maintenance
Installing the Westinghouse FA3020PF-R is a relatively straightforward task for qualified electricians. Its bolt-on style allows for firm mounting in panelboards and ensures a solid electrical connection.
Here are general steps for installation:
- Turn off the main power supply to the distribution panel.
- Confirm compatibility of the breaker with panel voltage and current ratings.
- Align and bolt the breaker into the designated slot.
- Connect conductors to the load-side lugs securely.
- Test the breaker by turning it ON and OFF before restoring the main supply.
Maintenance of the FA3020PF-R should include periodic visual inspections for signs of wear, corrosion, or overheating. Breakers in dusty or humid environments may require more frequent checks. Despite its reliability, any signs of malfunction—such as failure to trip or physical damage—should prompt immediate replacement or professional servicing.
Availability and Procurement
Although the Westinghouse FA3020PF-R is no longer in active production, it remains widely available through electrical surplus suppliers and reconditioning companies. Many companies offer refurbished units that are tested and certified for safe reuse.
When purchasing a replacement, make sure the unit:
- Is tested for functionality
- Comes with a service warranty (especially for reconditioned models)
- Is compliant with safety standards (e.g., UL listed or equivalent)
Suppliers like Eaton (which now owns many Westinghouse product lines), specialized surplus stores, and online marketplaces often stock this model or its equivalents.
Comparison with Similar Models
The FA3020PF-R belongs to a broader family of Westinghouse FA series breakers. Here’s how it compares:
| Model | Amps | Poles | Interrupting Capacity | Key Difference |
|---|---|---|---|---|
| FA3020PF-R | 20 | 3 | 14kA @ 480V | Standard model with bolt-on type |
| FA3020H | 20 | 3 | Higher fault tolerance | For high-interrupt applications |
| FB3020 | 20 | 3 | Varies | Slightly different frame size |
Compared to newer breakers, the FA3020PF-R may lack some digital features, but it remains preferred in systems that were originally designed with FA frame components.
User Experiences and Reviews
Electricians and maintenance professionals often praise the Westinghouse FA3020PF-R for its dependability and ease of integration into older systems. Here are a few commonly cited benefits:
- Reliable trip performance: Works consistently even in high-demand scenarios.
- Easy installation: Bolt-on mounting saves time during setup.
- Availability: Still accessible through surplus suppliers despite being out of production.
Some users note that sourcing authentic or certified reconditioned units can be challenging. Therefore, it’s essential to buy from reputable vendors and check for service records if possible.
Conclusion
The Westinghouse FA3020PF-R circuit breaker continues to serve as a dependable solution in industrial and commercial electrical systems. Its rugged molded case design, thermal-magnetic protection, and straightforward installation process make it a favored choice among engineers and electricians working with legacy systems.
Whether you’re upgrading a panel, maintaining existing infrastructure, or sourcing a replacement part, the FA3020PF-R remains a viable and reliable component. Just be sure to verify the source when purchasing, especially if opting for a reconditioned unit.
For those dealing with older electrical systems, this model offers a practical combination of proven technology and solid performance—making the Westinghouse FA3020PF-R more than just a legacy product, but a trusted solution that still delivers.
